OVERVIEW
Fits Every Drawer Type
Eliminate dangling cords and device clutter by adding a Blade Series outlet into any new or existing drawer. Docking Drawer's most versatile in-drawer outlet, the Blade can be installed in shallow, tall, narrow, and vertical drawers, mounts left- or right-facing, and can mount vertically or horizontally. Wherever you need hidden power, there is a Blade configuration that fits.
Most Popular Applications
- Bathroom vanity drawers: Keep your hair dryer, straightener, and electric toothbrush plugged in and ready for use, eliminating countertop clutter.
- Narrow drawers: Blade outlets can be installed into drawers as narrow as 9" by cutting a channel in the cabinet or by utilizing under-cabinet space. Learn more here.
- Office drawers: Power a printer on a pull out shelf, or create a dedicated charging zone for phones and laptops beside your desk.
- Appliance pull out drawers: Run a blender or other small appliance from inside an open kitchen drawer, keeping small appliances out of sight and freeing up valuable kitchen counter space.
Smart by Design
Blade Series outlets combine USB-C (PD), USB-A, and AC in flexible configurations that connect up to four devices, from phones and laptops to hair tools, printers, and small appliances. Its compact design fits every drawer type, while interchangeable outlet modules allow you to upgrade later as charging technology advances, making them a future-proof and enduring solution.
Simple to Plan and Install
Blade Series outlets work with shallow, tall, narrow, and vertical drawers, and are designed to fit into the standard 2" of space behind the drawer box, or as little as 1.25" with the use of a Spacer, in both standard and custom cabinetry. Every package includes detailed instructions, a cutout template, and all necessary screws, and installation requires only a few tools and basic DIY skills.
Safety & Code Compliance
All Blade outlets are ETL Listed for the US & Canada and feature an interlocking thermostat that cuts power at 120°F to prevent overheating. Premium all-metal construction is verified through rigorous cycle testing and backed by our industry-leading 5-year warranty.
Ensure NEC compliance (2023 edition):
- Kitchen, bathroom, and other drawers: Any Blade Series outlet is NEC compliant in all drawers except those in kitchen islands and peninsulas.
- Kitchen island and peninsula drawers: USB-only configurations (Blade 1514-180 or Blade Duo 1514-288) are allowed.
PROJECT PLANNING CHECKLIST
How to Plan Your Blade Project
Use this simple checklist to confirm drawer fit, choose the right power configuration, and plan your Blade installation with confidence.
Choose Your Room and Drawer Type
Start with where the Blade will go. The Blade fits all four drawer types: Shallow, Tall, Narrow, and Vertical. Vanity drawers and appliance pull-outs are typically tall, office and printer drawers are often shallow or vertical, and narrow drawers are common in pre-assembled vanities or alongside ranges and sink bases.
Verify Drawer Measurements
Measure the outside width (OD) of the drawer box. Installation requires 2" of space behind the drawer box, or 1.25" by adding a spacer.
- Shallow Drawer: At least 15" of outside drawer-box width and 3" of interior height
- Tall Drawer: At least 13" of outside drawer-box width and 4" of interior height
- Narrow Drawers: Fits drawers as narrow as 9" wide by applying our narrow drawer installation technique.
- Vertical Drawer: At least 8" of outside drawer-box width and 13" of interior height
| Drawer Type | Min Drawer Box Width (OD) | Min Interior Height |
|---|---|---|
| Shallow drawer | 15" | 3" |
| Tall drawer | 13" | 4" |
| *Narrow drawer | 9" | 4" |
| Vertical drawer | 8" | 13" |
*The Blade fits drawers as narrow as 9" wide by applying our narrow drawer installation technique.
Determine your Power and Configuration
- For hair tools and small appliances, prioritize AC outlets.
- For an office charging drawer, combine AC with USB-C (PD). Choose 65W USB-C (PD) for compatible laptops and larger technology, or 30W USB-C (PD) for phones and tablets.
- If you're looking to connect even more devices, check out our Blade Duo outlet which supports up to 8 device connections.
For most projects, 15 amp is the standard choice. Choose a 20 amp Blade outlet when the device or specified circuit requires it.
Shallow
Tall
Narrow
Vertical
TECHNICAL SPECS
Specifications
Outlet Dimensions
- Outlet Width: 13" [330mm]
- Outlet Height: 4.64" [118mm]
- Outlet Depth: 2.5" [64mm]
- Receptacle Box Depth: 1.93" [49mm]
- Cover Plate Height: 2.52" [64mm]
- Cover Plate Width: 7.18" [182mm]
- Cover Plate Thickness: 0.29" [7.5mm]
- Cable Management Arms Height: 3" [76mm]
- Cord Length (15 amp) from rear mounting bracket: 42" [1.07m]
- Cord Length (20 amp) from rear mounting bracket: 36" [0.9m]
Electrical Specs
- 65W USB-C (PD): 65W shared, 3 amps @ 9 VDC
- 30W USB-C (PD): 30W shared, 3 amps @ 9 VDC
- USB-A: up to 3.6 amps @ 5 VDC
- AC: 15 amps @ 120 VAC
Construction & Cord
- Plug Type: NEMA 5-15P
- Wire Gauge: 14 AWG
- Housing: All-metal construction
- Cable Type: Custom TPE (thermoplastic elastomer) jacket, ultra-flexible, PVC-free, and recyclable
- Cycle Testing: 500,000 open/close cycles (equivalent of 30 years of daily use), verified to meet original specifications throughout
- Strain Reliefs: Yes, at cord-to-connector transition points
- Cord Serviceability: Replaceable and field-serviceable without replacing the outlet
Safety Features
- Interlocking Thermostat: De-energizes automatically if internal temperature exceeds 120°F (49°C)
- Tamper Resistant: Yes
Electrical Certification
- ETL Listed for use in the US & Canada
- Certified to UL 962A (US)
- Certified to CSA C22.2 No. 21 (CA)
Warranty
- 5 Years
- Modifying the outlet voids certification and warranty (see details)
Front View
Top View
INSTALLATION
Installing your Blade
Installation requires a few basic tools, seven screws, and about thirty minutes for your average DIY-savvy homeowner or trade professional. The Blade outlet mounts to the back of the drawer box, and the 42" cord simply plugs into the nearest in-cabinet outlet.
Outlet Dimensions
Tower Height
6.7” [170mm]
Base Height
16.15” [410mm]
Cord Length
6' [1.9m
Minimum Space Required Below Countertop
18" [457.2mm]
Cutout Size
4" [102mm]
Under Mounting Flange Diameter
6.3" [160mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Material guidance
Suitable for a variety of materials, including stone and butcher block. If your countertop is thicker than 30mm, such as butcher block, keep the insert thickness under 30mm to allow proper use of the leveling set screws and flush alignment.
Countertop Insert Diameter
3.66” [93mm]
Can be installed so the outlet pops up, down or sideways.
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
FAQ
Blade Frequently Asked Questions
Outlet Dimensions
Tower Height
6.7” [170mm]
Base Height
16.15” [410mm]
Cord Length
6' [1.9m
Minimum Space Required Below Countertop
18" [457.2mm]
Cutout Size
4" [102mm]
Under Mounting Flange Diameter
6.3" [160mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Material guidance
Suitable for a variety of materials, including stone and butcher block. If your countertop is thicker than 30mm, such as butcher block, keep the insert thickness under 30mm to allow proper use of the leveling set screws and flush alignment.
Countertop Insert Diameter
3.66” [93mm]
Can be installed so the outlet pops up, down or sideways.
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
Max Countertop Material Thickness for Top Cup
Up to 1.18” [30mm]
