| Imperial | Metric | |
| Outlet Width | 11.16” | 283mm |
| Outlet Height | 4.64" | 118mm |
| Outlet Depth | 2.5" | 64mm |
| Receptacle Box Depth | 1.93" | 49mm |
| Cover Plate Height | 2.52" | 64mm |
| Cover Plate Width | 7.18" | 182mm |
| Cover Plate Thickness | 0.29" | 7.5mm |
| Cable Management Arms Height | 3" | 76mm |
| Cord Length (15 amp) measured from the rear mounting bracket | 54" | 1.37m |
| Cord Length (20 amp) measured from the rear mounting bracket | 36" | 0.9m |
| # | Outlet Configuration | Outlet Specifications |
| 1 | (2) USB-A & (2) AC | AC: 15 amps @ 120 VAC USB-A: 3.6 amps @ 5 VDC |
| 2 | (4) USB-A | 4.2 amps @ 5 VDC |
| 3 | (2) 30W USB-C & (2) AC | AC: 15 amps @ 120 VAC USB-C (single port connected to PD device): 3 amps @ 9 VDC (30W) USB-C (single port connected to non-PD device): 3 amps @ 5 VDC (15W) USB-C (both ports connected): 3 amps @ 5 VDC (30W total power) |
| 4 | (1) USB-C 30W, (1) USB-A & (2) AC | AC: 15 amps @ 120 VAC USB-C (non-PD device): 3 amps @ 5 VDC (15W) USB-A: 2.4 amps @ 5 VDC |
| 5 | (2) AC - GFCI | 15 amps @ 120 VAC |
| 6 | (2) AC | 15 amps @ 120 VAC |
| 7 | (2) 65W & (2) AC | AC: 15 amps @ 120 VAC USB-C (PD) 65 Watt Shared USB-C (single port connected to PD device): 65W 5V/3A; 9V/3A; 12V/3A; 15V/3A; 20V/3.25A USB-C (both ports connected to PD devices): 65W total C1/C2: 5V/3A; 9V/3A; 12V/2.5A; 15V/2A; 20V/1.5A |
| 8 | (2) 30W USB-C & (2) USB-A | USB-C (PD): 30 Watt Shared USB-C (single port connected to PD device): 30W max 5V/3A; 9V/3A; 12V/3A; 15V/3A; 15V/2A; 20V/1.5A USB-C (both ports connected): 15W each port C1:5V/3A C2:5V/3A USB-A (max with one or both ports connected) 12W total 5v/2.4A |
